Big Bag Filling Station RBB
The RBB-type big bag filling stations enable efficient filling of bulk bags.
The empty big bag is attached to four clamps at the upper corners of the frame. The bag’s inlet is then pulled over the filling spout of the system. Filling begins as soon as the seal around the bag’s inlet is inflated. Once the big bags are filled, they are lifted by a forklift, removed from the steel frame, and transported to their next destination.
RBB filling stations make big bag filling easy and dust-free.
Specifications
-
Materials: Carbon steel, stainless steel 304 L
-
Inflatable seal for dust control during bag filling
-
Fixed or adjustable frame height
-
Spring clamps for easy bag attachment
-
Suitable for big bags up to 2,000 mm
Available Variants
-
Standard version
-
Product-contact parts in AISI 304
-
Entirely in AISI 304
Optional Accessories
-
Pneumatic control panel
-
Exhaust fan
